Moulded Rubber Products
62
BLANKING GROMMETS
PART No.
A
mm
B
mm
C
mm
D
mm
M0034-001
12.7
1.2
7.2
9.5
M0039-002
20.6
1.6
7.2
17.5
M0041-001
54.0
1.2
6.0
47.6
M0041-102
57.0
1.0
6.4
35.0
M0058-105
57.1
1.2
9.5
44.5
M0115-001
17.5
1.6
6.4
12.7
M0128-001
19.0
1.6
6.4
14.3
M0129-001
38.1
1.6
8.0
31.8
M0159-001
11.0
1.6
4.8
8.0
M0160-001
25.4
1.6
6.4
19.0
M0161-001
20.6
1.6
6.4
16.0
M0171-001
16.0
1.6
6.4
11.0
M0194-001
31.8
1.6
0.8
25.4
M0228-001
25.4
0.8
8.0
14.3
M0240-001
28.6
1.6
6.4
22.3
M0251-001
58.0
1.6
7.2
36.5
M0261-001
33.3
1.6
8.0
27.0
M0273-001
44.5
1.6
8.0
38.1
#M0273-001GR
44.5
1.6
8.0
38.1
M0323-001
59.0
1.5
7.5
50.5
M0338-001
53.0
2.4
8.7
35.0
A
D
B
C
#Special order only - Minimum order quantities apply
Series 2
