LPG VAPOUR HOSE
Codan Vapour Hose is speci cally designed to carry
vapours from automotive LPG conversions.
The hose is manufactured from neoprene based
tube and is encased in a braided cotton outer
reinforcement. It is oil and petrol resistant.
BRAKE VACUUM HOSE
Codan Brake Vacuum Hose is designed to transmit
manifold vacuum in automotive power assisted
braking systems. It is manufactured from neoprene
and reinforced with rayon.
Manufactured to SAE J 1403 it is resistant to oil,
petrol, heat and weather.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
#2601120/20M
12 1/2
3.2 18.4
20 2.0
60
20
20
2601170/20M
17 21/32
3.5 23.4
20 2.0
80
20 20
2601190/20M
19
3/4 3.5
26
20
2.0
90 20
20
2601250/20M
25 1
4.5 34
20
2.0
100 20 20
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Vacuum tested to
Bend Radius
mm
Weight
gm/m
Length
m
4205095/7M
9.5 11/32
4
17.5
87% 30
252
7
4205095/30M
9.5 11/32
4
17.5
87%
30
252
30
4205120/7M
12.5 1/2
4
20
87%
30 299 7
#4205120/30M
12.5 1/2
4
20
87%
30 299 30
#Special order only - Minimum order quantities apply
#Special order only - Minimum order quantities apply
