FUEL INJECTION HOSE
Codan EFI Fuel Injection Hose is designed to run at higher pressures
and temperatures than normal systems.
The inner tube is made of NBR (Nitrile) with an outer cover of CSM
(Hyperlon) and reinforcing made of Kuralon.
This hose is suitable for Petrol with a maximum E10 rating and Diesel
with a maximum B5 rating, it is not suitable for Fuel above E10 or B5.
The hose conforms to SAE J30 R7 and GME 08001E Spec.
This hose is not submersible for in tank use.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
5250075/7M
7.5
5/16
3.5
14.5
3.4
0.34
25
200 7
5250075/30M
7.5 5/16
3.5
14.5
3.4
0.34
25 200 30
5250095/7M
9.5
3/8 3.6
16.7
3.4
0.34
40
210
7
5250095/30M
9.5
3/8 3.6
16.7
3.4
0.34
40
210
30
R9 FUEL INJECTION HOSE
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
H533063/7M
6.3
1/4 3.05
12.4
6.9
0.69
20
140
7
H533079/7M
7.9
5/16
3.05
14.0
6.9
0.69
25
155
7
H533095/7M
9.5
3/8 3.15
15.8
6.9
0.69
40
205
7
#H533127/7M
12.7
1/2
3.20
19.1
6.9
0.69
50
250
7
Codan R9 EFI Fuel Injection Hose is designed to run at higher
pressures and temperatures than normal Fuel Injection Hoses.
The inner liner is made of FKM (Viton), the inner tube from NBR
(Nitrile) with an outer cover of CSM (Hyperlon).
This hose is suitable for Petrol with a maximum E20 rating and Diesel
with a maximum B10 rating, it is not suitable for Fuels above E20 or
B10.
The hose conforms to SAE J30 R9.
This hose is not submersible for in tank use.
