Series 2
Automotive Hose
44
90 DEGREE HOSE BEND
These 90 degree Universal Hose Bends are available in the
most popular sizes.
Manufactured to Codan's high standards these hose bends are
suitable for an array of automotive and industrial uses.
PART No.
I.D.
mm
A
mm
PCHNB9
9.45 290
PCHNB13
12.7 290
PCHNB16
15.9 290
PCHNB19
19.05 290
PCHNB22
22.25 290
PCHNB25
25.4 290
PCHNB35
34.95 290
PCHNB37
37.8 290
PCHNB38
38.1 290
A
A
POWER STEERING RETURN HOSE
Codan Power Steering Return Hose is designed speci cally as
low pressure side return hose for vehicle power steering systems.
It is manufactured with a nitrile inner, reinforced with polyester
and covered by a neoprene outer that is resistant to oil, fuel and
heat.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
5130079/7M
7.9 5/16
4
16 17.2 1.72
25
224
7
#5130079/30M
7.9 5/16
4
16
17.2
1.72
25 224 30
5130100/7M
10 3/8
4 16
17.2
1.72
40 242 7
#5130100/30M
10 3/8
4 16
17.2
1.72
40 242 30
Operating temperature range is -40 degees C to +121 degrees C
with a safety factor of 4:1. This hose is manufactured to SAE
J 189 Spec.
#Special order only - Minimum order quantities apply
