Series 2
Automotive Hose
40
HEATER HOSE
Codan Heater Hose has been specially developed for vehicle coolant
systems and has a safety factor of 3:1. It is suitable for use over a
temperature range of -40 degrees C. to +100 degrees C.
The hose is manufactured from a rubber and EPDM blend and is twin
braided spiral wrap reinforced, conforming to SAE 20 R3. It is weather
resistant and impervious to coolant system additives.
It is not suitable for use with petrochemical products.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
4801050/30M
5
13/64
3.2
11.5
10
1.0
29.0
110
30
4801080/30M
8 5/16 3.0 14.0
10
1.0
40 200 30
4801095/25M
9.5 3/8 3.75 17.0
10
1.0
50 220 25
#4801095/50M
9.5 3/8 3.75 17.0
10
1.0
50 220 50
4801095/100M
9.5 3/8 3.75 17.0
10
1.0
50 220 100
4801127/15M
12.7 1/2
3.4 19.5
10
1.0
50 240 15
#4801127/50M
12.7 1/2
3.4 19.5
10
1.0
50 240 50
4801127/100M
12.7 1/2
3.4 19.5
10
1.0
50 240 100
4801160/15M
16 5/8
3.4 22.8
10
1.0
80 290 15
4801160/50M
16 5/8
3.4 22.8
10
1.0
80 290 50
4801160/100M
16 5/8
3.4 22.8
10
1.0
80
290 100
4801191/15M
19 3/4 3.6 26.3
10
1.0
100 360 15
4801191/50M
19 3/4 3.6 26.3
10
1.0
100 360 50
#Special order only - Minimum order quantities apply
FUEL HOSE - OUTER BRAIDED
Codan Braided Fuel Hose is designed for use on
many European vehicles and motor cycles.
The tube is manufactured from a nitrile based
rubber and it is encased in an outer braiding of
non-conductive black cotton. It is resistant to oil
and petrol. This hose is manufactured to DIN 73379
TYPE B Spec.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
#506055/15M
5.5 7/32
2.5 10.5 10 1.0
20
94
15
#506075/15M
7.5 9/32
2.5 12.5
9 0.9
30
114
15
#506095/15M
9.5
3/8
2.5
14.5
6
0.6
40
135
15
#Special order only - Minimum order quantities apply
