Series 2
Automotive Hose
42
LPG / INJECTION HOSE
Codan Automotive Gas Hose is designed speci cally
to meet AS/NZS 1869 class D standard for use in
LPG and CNG fuel conversions. The class D rating is
the highest classi cation and this hose can replace
any other hoses of ECE67 Class 2 and DIN4815 teil4
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Working Pressure
Bar Mpa
Bend Radius
mm
Weight
gm/m
Length
m
#H251T040/25M
4 7/32 2.6 26
26.0 2.6
110
35
25
#H251T060/25M
6 1/4
2.6 26
26.0
2.6
140 50 25
#H251T100/25M
10 3/8
2.6
26
26.0
2.6
210 80 25
#H251T120/25M
12 15/32
3.5
19
26.0
2.6
48
235
25
Printing on Hose:
XXX (Codan Logo) CODAN LPG HOSE AS/NZS1869
CLASS D ID XX (LOT NO. XXX)
#Special order only - Minimum order quantities apply
RADIATOR OVERFLOW HOSE
Codan Radiator Over ow Tubing is suitable for
radiator over ow and header tank applications.
It is manufactured from EPDM rubber and will with
stand radiator temperatures and pressures as well as
vacuum. It is weather and radiator additive resistant.
PART No.
I.D.
mm inch
Wall Thickness
mm
O.D.
mm
Length
m
3300079/15M
8
5/16
2
12
15
3300095/15M
10
3/8
2
14
15
#Special order only - Minimum order quantities apply
